SIZE

TYPE

A

B

D

E

STANDARD
BORE

BORE METRIC

BORE INCH

MIN

MAX

MIN

MAX

LO35

1

16

20.5

6.6

-

3

3

8

1/8"

3/8"

L050

1

28

43.2

15.6

-

6

5

15

3/16"

5/8"

L070

1

35

50.8

19

-

9

7

19

3/16"

3/4"

L075

1

45

54.7

21

-

9

9

25

3/16"

1"

L090

1

54

54.7

21

-

9

9

28

3/16"

1 1/8"

L095

1

54

63.7

25.5

-

9

9

28

3/8"

1 1/8"

L099

1

64.5

72.5

27

-

12

12

35

7/16"

1 3/8"

L100

1

64.5

88.5

35

-

12

12

35

7/16"

1 3/8"

L110

1

85

108

43

-

15

15

48

1/2"

1 7/8"

L150

1

96

115.4

45

-

15

15

48

5/8"

1 7/8"

L190

2

115

133.4

54

101.6

19

19

55

5/8"

2 1/4"

L225

2

127

153.4

64

108

19

19

65

3/4"

2 5/8"
